V7-9W1AE9-048 by honeywell

V7-9W1AE9-048

Honeywell

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 15.1 A 125, 250, or 277 Vac, 59,4 mm [2.34 in] Straight Lever Actuator, 90 g [3.17 oz] Maximum Operating Force, 2,9 mm [0.11 in] Mounting Holes, -40 °C to 177 °C [-40 °F to 350 °F] Temperature Range, 6,35 mm x 0,81 mm [0.250 in x 0.032 in] Quick Connect Spread Termination, UL, CSA ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Snap action switches are highly sensitive switches that respond to very small movements and can rapidly change from one contact position to the other and are therefore mostly used in timing devices, vending machines, computer and business equipment, test instruments, HVAC equipment, office equipment, manually operated devices, valves, gaming equipment and pressure switches.

V7-9W1AE9-048 Snap Action Switch comes with world-wide package size acceptance and features a current rating ranging from 0.1 A to 25 A. V7-9W1AE9-048 Snap Action Switch from Honeywell is specially designed for 100K operations at a full load and has a long mechanical life of up to 10M. This Honeywell switch is best suited for higher cost-of-failure applications.

Product Highlights:

  • World-wide package size acceptance
  • Current rating ranges from 0.1 A to 25 A
  • Best suited for higher cost-of-failure applications
  • Designed for 100K operations at a full load or 10M for mechanical life
  • UL/CSA and ENEC approvals

Potential Applications:

  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves
  • Gaming equipment
  • Pressure switches

Search Keywords: V79W1AE9048

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V7-9W1AE9-048
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Straight Lever
Contact Rating @ Voltage:
15.1@277VAC@(CSA/UL) A
Maximum Movement Differential:
1.37 mm
Operating Force:
0.88 N
Termination Style:
Quick Connect
Dimension:
73.88 x 10.16 x 29.51 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 857

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 9 Weeks

Price (CAD)

Qty
Unit Price
5
$11.913
25
$7.212
50
$7.166
200
$7.090
400
$7.059
600
$7.029
1,000 +
$6.983
