MR-20F by htk honda
Image is representational - see mfr. specs

MR-20F

HTK HONDA

Conn Rectangular F 20 POS 2.6mm Solder Lug ST Panel Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MR-20F is a female connector from the MR series designed for soldering applications with 20 contact positions. It features a diethyl phthalate resin insulator body in blue with phosphor bronze contacts available in silver or gold plating finishes. The connector accommodates cables up to AWG#22 maximum and is designed for panel mounting with recommended hole dimensions of Ø2.8 mm. Key dimensional specifications include an overall length (A) of 32.8 mm, width (B) of 27.8 mm, and contact depth (C) of 22.3 mm, with contact spacing of 2.6 mm. This connector is suitable for automotive and industrial applications requiring reliable soldered connections with standardized mechanical and electrical interfaces.

Search Keywords: MR20F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
HTK HONDA
Part No:
MR-20F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694030
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Rectangular
Mounting:
Panel Mount
Body Orientation:
Straight
Pitch:
2.6 mm
Termination Method:
Solder
Number of Contacts:
20
Maximum Voltage Rating:
300 VAC
Maximum Current Rating:
3/Contact A
Operating Temperature:
N/A

IN STOCK: 0

Minimum Order Quantity: 15

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
15
$11.92
85
$9.36
100 +
$8.03
Log in for special pricing Click for Quote Price Match Request
