PCS-E20LB

Backshell 180° Die Cast ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PCS-E20LB is a vertical type die-cast material backshell for standard cable, part of the PCS series 1.27 mm pitch connector family designed for high-density board-to-cable interfaces in downsized electronic equipment. This 20-contact backshell features an EMI-filtered design to meet FCC and other standards, with a robust interface structure and quick locking via metal latch. The connector accommodates cables with an outside diameter of approximately ø7.5 mm and includes a cable clamp, latch mechanism, and Phillips head screws for secure mounting. The backshell dimensions are 30.0 mm (A) × 20.3 mm (B) with an 8×7 mm cable outlet (C), making it suitable for office automation equipment and other applications requiring compact, reliable interconnections with low insertion force and drainage structure for flux removal.

Search Keywords: PCSE20LB

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
HTK HONDA
Part No:
PCS-E20LB
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
600
Type:
Backshell
Shell Size:
N/A
Angular Function:
180 °

IN STOCK: 0

On Order: 600   can ship 6/14/27

Minimum Order Quantity: 25

Factory Lead-Time 35 Weeks

Price (USD)

Qty
Unit Price
25
$7.82
50
$7.80
100
$7.46
250
$6.85
600
$6.67
1,200
$6.49
3,000 +
$6.41
Supplier's Standard Package
