AP1M122-G by idec corporation
Image is representational - see mfr. specs

AP1M122-G

IDEC Corporation

LED Panel Mount Indicator Uni-Color Green 2-Pin ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AP1M122-G is a miniature 10mm pilot light from the AP1 series featuring a flat lens design and built-in LED with current-limiting resistor. It operates at 5V DC (±5%), 12V AC/DC (±10%), or 24V AC/DC (±10%), with current ratings of 9mA at 5V and 12V DC, and 15mA at 12V and 24V AC. The device is rated for operating temperatures from -20°C to +55°C with 45–85% relative humidity, and provides IP65 protection (oiltight). It features 100MO minimum insulation resistance (500V DC megger) and 200V reverse withstand voltage, with solder terminals rated for 260°C maximum (5 seconds). The AP1M122-G is commonly used in industrial control panels, machinery status indication, and signaling applications where space-saving miniature indicators are required.

Search Keywords: AP1M122G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
AP1M122-G
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541402000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Panel
Dimension:
31.5 x 12 mm
Type:
Uni-Color
Maximum Forward Voltage per Color:
26.4 V
Color:
Green
Peak Wavelength:
N/A
Lens Shape Type:
Circular
Lens Appearance:
N/A
Lens Dimensions:
N/A
Intensity:
N/A
Viewing Angle:
N/A
Maximum Forward Current:
N/A

IN STOCK: 0

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$9.93
25
$8.99
50
$8.59
100
$8.34
250
$7.89
500
$7.67
1,000 +
$7.58
