AP1M222-PW by idec corporation
Image is representational - see mfr. specs

AP1M222-PW

IDEC Corporation

LED Panel Mount Indicator Uni-Color White 2-Pin ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AP1M222-PW is a miniature 10mm pilot light from IDEC's AP Series, featuring a built-in LED with integrated current-limiting resistor and a cool white lens. It operates at 24V AC/DC with ±10% tolerance and draws 9 mA at 24V DC or 15 mA at 24V AC, providing reliable visual indication in industrial control panels and signaling applications. The unit is rated for -20°C to +55°C operating temperature with 45–85% RH humidity, offers IP65 protection (oiltight), and features 100 MO minimum insulation resistance and 200V reverse withstand voltage. With its space-saving dome lens design, built-in current-limiting resistor, and long service life, the AP1M222-PW is ideal for compact panel-mount applications requiring durable, low-maintenance status indication across industrial machinery, process control systems, and equipment monitoring.

Search Keywords: AP1M222PW

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
AP1M222-PW
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541402000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Panel
Dimension:
31.5 x 12 mm
Type:
Uni-Color
Maximum Forward Voltage per Color:
24 V
Color:
White
Peak Wavelength:
N/R
Lens Shape Type:
Circular
Lens Appearance:
N/A
Lens Dimensions:
N/A
Intensity:
N/A
Viewing Angle:
N/A
Maximum Forward Current:
15 mA

IN STOCK: 34

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$9.30
25
$8.71
50
$8.47
100
$8.22
250
$7.88
500
$7.63
1,000 +
$7.39
Log in for special pricing Click for Quote Price Match Request
