AP8M222-G

LED Panel Mount Indicator Uni-Color Green 2-Pin ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The AP8M222-G is a miniature 8mm pilot light from IDEC's AP Series, featuring a built-in LED with integrated current-limiting resistor and a dome lens design. It operates at 24V AC/DC (±10% tolerance) with a current rating of 15mA for AC and 9mA for DC, providing reliable visual indication in compact panel-mounted applications. The unit is rated for operating temperatures from -20°C to +55°C with 45–85% RH humidity, and offers IP40 protection (dustproof). With an insulation resistance of 100MO minimum and a reverse withstand voltage of 200V, this pilot light is suitable for industrial control panels, machinery status indication, and process monitoring systems where space is limited and long service life is required.

Search Keywords: AP8M222G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
AP8M222-G
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541402000
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Mounting:
Panel
Dimension:
31 x 9.8 mm
Type:
Uni-Color
Maximum Forward Voltage per Color:
26.4 V
Color:
Green
Peak Wavelength:
N/A
Lens Shape Type:
Circular
Lens Appearance:
N/A
Lens Dimensions:
N/A
Intensity:
N/A
Viewing Angle:
N/A
Maximum Forward Current:
9 mA

IN STOCK: 30

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$17.10
25
$13.21
50
$12.48
100
$10.19
250
$9.87
500
$9.45
1,000 +
$9.42
