ASW500-1 by idec corporation

ASW500-1

IDEC Corporation

The ASW500-1 is a 5-position, maintained selector switch operator from the ø22mm TW series for sub-assembled configurations. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ASW500-1 is a 5-position, maintained selector switch operator from the IDEC ø22mm TW series, designed for modular panel applications. This component utilizes a specific 'Cam 1' profile to determine the contact actuation sequence across its five positions when paired with compatible contact blocks. As part of the TW series, it supports systems with a rated insulation voltage of 600V and a thermal current of 10A. The operator contributes to a panel assembly with an IP65 degree of protection from the front and a mechanical life of 500,000 operations. Its modular nature provides flexibility for creating custom switch assemblies for industrial control, automation, and machinery.

Search Keywords: ASW5001

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
ASW500-1
Unit of Measure:
Per Each
RoHS:
Yes
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1

IN STOCK: 0

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$11.06
25
$10.02
50
$9.58
100
$9.30
250
$8.79
500
$8.56
1,000 +
$8.45
Log in for special pricing Click for Quote Price Match Request
