HW1B-M1F22-B

A 22mm momentary, non-illuminated round flush pushbutton switch with a black plastic bezel and a 2NO-2NC contact configuration. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The HW1B-M1F22-B is a non-illuminated, momentary action pushbutton switch from the HW series, designed for a 22mm panel cutout. It features a black, round flush operator with a plastic bezel and provides a 2NO-2NC contact configuration. The switch incorporates finger-safe (IP20) contact blocks with slow make, double-break, self-cleaning silver contacts, a rated insulation voltage of 600V, and a thermal current of 10A. This robust switch is easy to assemble and suitable for a wide range of industrial control applications requiring reliable momentary switching, benefiting from worldwide approvals and a high mechanical life.

Search Keywords: HW1BM1F22B

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
HW1B-M1F22-B
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509035
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Mounting:
Panel Mount
Pole Throw Configuration:
4PST
Bushing Type:
Threaded
Switch Configuration:
N.O./N.C.
Contact Rating @ Voltage:
745.7 A
Actuator Style:
Flush Round Button
Illumination:
N/R
Terminal Type:
Screw
Body Orientation:
Straight

IN STOCK: 0

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$34.92
5
$32.66
10
$31.16
25
$30.22
50
$28.93
100
$27.74
250 +
$27.00
