HW1F-2F20QD-G-120V by idec corporation
Image is representational - see mfr. specs

HW1F-2F20QD-G-120V

IDEC Corporation

Switch Selector N.O. DPST 90° Knob 10A 440VAC 220VDC 745.7VA Screw 500000Cycles Panel Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HW1F-2F20QD-G-120V is an illuminated 22mm extended flush pushbutton switch designed for industrial control applications requiring visual feedback. This unit features a 2NO (2 normally open) contact arrangement with full voltage LED illumination operating at 120V AC, providing reliable switching and bright indication in panel-mounted installations. The switch incorporates IDEC's proven HW Series design with slow make double break self-cleaning contacts, finger-safe IP20 contact blocks, and a plastic bezel with green lens for standard industrial signaling. The momentary function with extended operator provides ergonomic control, while the LED lamp offers energy efficiency and long service life compared to incandescent alternatives. This switch is suitable for machinery control, process automation, and equipment status indication where 120V AC powered illumination is available.

Search Keywords: HW1F2F20QDG120V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
HW1F-2F20QD-G-120V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
2 Position
Pole Throw Configuration:
DPST
Actuator Style:
Knob
Illumination Color:
Green
Illumination Type:
LED
Typical Illumination Voltage:
120 VAC
Maximum Current Rating:
10@110VAC A
Terminal Type:
Screw
Angle of Throw:
90 °
Number of Positions:
2
Switch Configuration:
N.O.

IN STOCK: 0

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
1
$42.46
5
$39.73
10
$38.55
25
$37.00
50
$35.82
100
$34.65
250 +
$33.09
Log in for special pricing Click for Quote Price Match Request
