HW7D-L11F1001Q4W-WB1

The HW7D-L11F1001Q4W-WB1 is a 22mm panel-mount dual pushbutton switch with momentary action, a 1NO top button, a 1NC bottom button, and an integrated 24V AC/DC white LED pilot light. ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The HW7D-L11F1001Q4W-WB1 is a dual pushbutton switch from the HW Series, integrating two pushbuttons and a pilot light into a single space-saving ø22 mm control unit. This model features two momentary, flush-style buttons: the top button is white with 'I/ON' engraving and a 1NO contact, while the bottom button is black with 'O/OFF' engraving and a 1NC contact. The central pilot light is a full-voltage white LED rated for 24V AC/DC. The unit utilizes finger-safe IP20 contact blocks with a rated thermal current of 10A and a rated insulation voltage of 600V. Its compact design makes it ideal for power and start/stop switch applications in industrial control panels where clear visual status indication is required.

Search Keywords: HW7DL11F1001Q4WWB1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
HW7D-L11F1001Q4W-WB1
Unit of Measure:
Per Each
RoHS:
Yes
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1

IN STOCK: 0

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
1
$48.09
5
$42.91
10
$41.63
25
$40.43
50
$38.21
100
$37.19
250 +
$36.70
