LW1B-M1C5-G by idec corporation
Image is representational - see manufacturer specifications
IDEC Corporation Authorized Distributor

LW1B-M1C5-G

Switch Push Button N.O./N.C. SPDT Flush Round Button 3A 250VAC 125VDC Momentary Contact Quick Connect/Solder Panel Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The LW1B-M1C5-G is an illuminated pushbutton switch from IDEC's LW Series Flush Silhouette Switches, featuring a round flush design with black plastic bezel and momentary operation. It is configured with silver contacts in a DPDT (double-pole double-throw) contact form, providing dual independent switching circuits. The switch is rated for AC operation at 125 V with 2 A resistive load and 2 A inductive load (50/60 Hz, PF 0.6–0.7), and DC operation at 30 V with 2 A resistive load and 1 A inductive load (L/R = 7 ms max). Contact material is silver with a maximum contact resistance of 50 mO and insulation resistance of 100 MO minimum (500 V DC megger). The switch operates reliably across -25 °C to +50 °C (illuminated units) and is suitable for industrial control panels, machinery interfaces, and automation systems requiring dual-circuit momentary switching with visual feedback.

Search Keywords: LW1BM1C5G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
LW1B-M1C5-G
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509031
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Mounting:
Panel Mount
Pole Throw Configuration:
SPDT
Bushing Type:
Threaded
Switch Configuration:
N.O./N.C.
Contact Rating @ Voltage:
3A@125 VAC
Actuator Style:
Flush Round Button
Illumination:
N/R
Terminal Type:
Quick Connect/Solder
Body Orientation:
Straight

IN STOCK: 0

On Order: 30   can ship 12/4/26

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$50.55
5
$33.50
10
$32.02
25
$29.14
50
$27.78
100
$21.60
250 +
$21.55
