RR3B-ULCDC24V by idec corporation
Image is representational - see manufacturer specifications
IDEC Corporation Authorized Distributor

RR3B-ULCDC24V

Power Relay 24VDC 10A 3PDT(36x36x47.5)mm Socket ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The RR3B-ULCDC24V is a 3-pole general-purpose power relay manufactured by IDEC with a 24 VDC coil and blade-style termination, featuring an indicator light and check button for test operation. The relay operates at a rated coil voltage of 24 VDC with a coil current of 60 mA and coil resistance of 400 O at 20 °C, with an operating time of 25 ms maximum and release time of 25 ms maximum. Contact ratings include 10 A at 30 VDC resistive load and 7.5 A at 30 VDC inductive load, with silver contact material and a maximum contact resistance of 30 mO. The relay is rated for a minimum operating voltage of 80% of rated voltage and a maximum continuous applied voltage of 110% of rated voltage, with a minimum applicable load of 24 V DC/10 mA. This relay is commonly used in industrial control systems, automation equipment, and power distribution applications where reliable switching of moderate DC loads is required.

Search Keywords: RR3BULCDC24V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
RR3B-ULCDC24V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
TH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
3PDT
Mounting:
Socket
Termination Style:
Solder
Push to Test Button:
Yes
Led Indicator:
Yes
Operating Temperature:
-30 to 70 °C
Coil Resistance:
400 Ohm

IN STOCK: 84

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$25.47
10
$24.19
25
$22.55
50
$21.20
100
$19.95
250
$19.90
500 +
$19.85
Log in for special pricing

Tools/3D Models

Product Guides
