XN1E-BV422MR by idec corporation
Image is representational - see mfr. specs

XN1E-BV422MR

IDEC Corporation

Switch Emergency Stop N.O./N.C. DPST/DPST Mushroom Button 5A 250VAC 250VDC 32N Screw Panel Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The XN1E-BV422MR is a non-illuminated emergency stop switch with a 40mm mushroom operator head, plastic bezel, and 2NC main contacts combined with 2NO monitor contacts. It features IDEC's proprietary "safe break action" mechanism that ensures contacts remain open when the contact block is detached, along with a safety-lock mechanism compliant with IEC60947-5-5 (6.2). The device operates with a 2-in-1 push-to-lock and pull/turn-to-reset action, incorporating a Direct Opening Action mechanism (IEC60947-5-5, 5.2) with a minimum force requirement of 80N and a 4mm operator stroke. It achieves IP65 degree of protection, operates across -25°C to +60°C, and is rated for 100,000 mechanical operations minimum with a contact resistance of 50mO maximum and 100MO minimum insulation resistance. This emergency stop is ideal for industrial machinery, control panels, and safety-critical applications requiring reliable emergency shutdown with redundant contact monitoring.

Search Keywords: XN1EBV422MR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
XN1E-BV422MR
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536507000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Actuator Diameter:
40 mm
Actuator Color:
Red
Pole Throw Configuration:
DPST/DPST
Illumination Type:
N/R
Illumination Color:
N/R
Maximum AC Voltage Rating:
250 V
Maximum DC Voltage Rating:
250 V
Maximum Current Rating:
5@125VAC A
Terminal Type:
Screw
IP Rating:
IP65

IN STOCK: 12

Ships today, if you order in

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$81.24
5
$76.23
10
$74.08
20
$71.91
50
$69.06
100 +
$66.91
