XN1E-LV413Q4MR by idec corporation
Image is representational - see mfr. specs

XN1E-LV413Q4MR

IDEC Corporation

Switch Emergency Stop N.O./N.C. SPST/3PST Mushroom Button 5A 250VAC 250VDC 32N Screw Panel Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The XN1E-LV413Q4MR is an illuminated emergency stop switch featuring a 40mm mushroom operator with 3 normally closed (3NC) main contacts and 1 normally open (1NO) monitor contact. This plastic bezel e-stop operates on 24V AC/DC ±10% with 15mA LED current and incorporates IDEC's safe break action mechanism ensuring contacts remain open when the contact block is detached. The device features push-to-lock and pull/turn-to-reset operation with operating forces of 32N for push-to-lock and 21N for pull-to-reset, along with a turn-to-reset torque requirement of 0.27 N·m. It is rated for -25°C to +55°C operating temperature (illuminated model), 45–85% RH humidity, and achieves IP65 protection at the operator and IP20 at the terminal. The switch delivers 250,000 minimum mechanical operations and 100,000 minimum electrical operations at rated load, with contact resistance of 50mO maximum and gold-plated silver contacts. Common applications include industrial machinery emergency shutdown systems, safety-critical control panels, and hazardous area equipment requiring reliable latching emergency stop functionality with visual indication.

Search Keywords: XN1ELV413Q4MR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
XN1E-LV413Q4MR
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Actuator Diameter:
40 mm
Actuator Color:
Red
Pole Throw Configuration:
SPST/3PST
Illumination Type:
LED
Illumination Color:
Red
Maximum AC Voltage Rating:
250 V
Maximum DC Voltage Rating:
250 V
Maximum Current Rating:
5@125VAC A
Terminal Type:
Screw
IP Rating:
IP65

IN STOCK: 0

On Order: 10   can ship 7/13/26

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$126.80
5
$124.73
10
$124.13
20
$123.82
50
$123.51
100 +
$123.20
