DAM-7W2P-K87 by itt cannon
Image is representational - see mfr. specs

DAM-7W2P-K87

ITT CANNON

D Subminiature Connector - 7 Contact - Male - Solder Terminal - Plug ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The DAM-7W2P-K87 is a Combo D Series D-Subminiature connector offering mixed layouts with a 7W2 contact arrangement (5 contacts size 20 and 2 empty size 8 cavities). This connector supports wire gauges from AWG 8-26 and is rated for a maximum signal current of 7.5 A with a contact resistance of 10 mO maximum. It features a dielectric withstanding voltage of 500 VAC at sea level and operates reliably across a temperature range of -55°C to +125°C, with a rated mating cycle life of 50 cycles. The connector is designed for industrial and aerospace applications requiring robust interconnection with mixed signal and power configurations, offering excellent reliability through salt spray testing (20 hours) and consistent electrical performance.

Search Keywords: DAM7W2PK87

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
DAM-7W2P-K87
Alias/AKA:
053512-1280
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694030
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
70
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
Pin
Termination Method:
Solder Cup
Shell Size:
A
Number of Contacts:
5Signal/2Cavity
Contact Plating:
Gold Over Nickel,Gold Over Copper
Operating Temperature:
-55 to 125 °C

IN STOCK: 399

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
5
$20.78
25
$13.02
70
$11.07
140
$10.82
280
$9.96
560
$9.82
1,050 +
$9.76
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models
