DBM-25S-D by itt cannon
Image is representational - see manufacturer specifications
ITT CANNON Authorized Distributor

DBM-25S-D

D Subminiature Connector - 25 Contact - Female - 0.109 inch Pitch - Solder Terminal - Hole .12 - Receptacle ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The ITT Cannon DBM-25S-D is a D Subminiature Connector that features 25 female contacts with a 0.109 inch pitch. This connector utilizes solder terminals with a hole size of 0.12, making it suitable for a variety of applications. The DBM-25S-D is a reliable and high-quality receptacle connector perfect for your electrical connectivity needs.

Search Keywords: DBM25SD

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
DBM-25S-D
Alias/AKA:
053513-1257
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
B
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 125 °C

IN STOCK: 99

Can Ship immediately

MOQ for out of Stock Qty: 25

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
1
$165.55
5
$165.14
10
$164.73
25
$164.32
50
$86.99
75
$61.21
100 +
$59.99
Log in for special pricing Click for Quote Price Match Request
