DBMA-25S by itt cannon
Image is representational - see mfr. specs

DBMA-25S

ITT CANNON

D Subminiature Connector - 25 Contact - Female - 0.108 inch Pitch - Crimp Terminal - Hole .12 - Receptacle ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

DBMA-25S is a high-reliability D-Sub connector from the D'MA series featuring crimp termination. It incorporates 25 socket contacts (size 20) with gold over nickel finish on copper alloy contacts, providing excellent electrical performance with a current rating of 7.5 A max and contact resistance of 10 milliohm max. The connector features a steel shell with yellow chromate over zinc finish and a black thermoplastic PCT UL 94V-0 insulator, supporting an operating temperature range of -55°C to +125°C. With a dielectric withstanding voltage of 1000 VAC at sea level and 200 mating cycles, this connector is suitable for demanding applications requiring reliable signal and power connections in industrial, aerospace, and military environments.

Search Keywords: DBMA25S

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
DBMA-25S
Alias/AKA:
050911-0002
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694030
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Crimp
Shell Size:
B
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 125 °C

IN STOCK: 78

Can Ship immediately

MOQ for out of Stock Qty: 13

Factory Lead-Time 21 Weeks

Price (USD)

Qty
Unit Price
1
$122.73
5
$101.27
10
$98.09
13
$94.05
25
$93.11
38
$92.20
50 +
$91.28
Log in for special pricing Click for Quote Price Match Request
