DL1-P-D/C by itt cannon
Image is representational - see mfr. specs

DL1-P-D/C

ITT CANNON

The DL1-P-D/C is a 156-contact, plastic-body, zero-insertion-force (ZIF) plug connector for multiple-wire power and signal applications. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The DL1-P-D/C is a 156-contact, plastic-body, zero-insertion-force (ZIF) plug connector designed for high-performance, multiple-wire power and signal connections. It features a durable UL 94V-1 rated glass-filled thermoplastic housing and supports various contact types, including crimp and square post, accommodating wire sizes from #18 to #42 AWG. The connector is rated for a minimum of 10,000 mating cycles and operates over a temperature range of -55°C to 105°C. It has a current rating of 5 A maximum per contact and a dielectric withstanding voltage of 1200 VAC RMS. Mating is achieved with a single-hand actuated rotating latch, making it ideal for applications in medical diagnostics, automated test equipment, and industrial automation.

Search Keywords: DL1PDC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
DL1-P-D/C
Alias/AKA:
025-0852-000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
3923500000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1

IN STOCK: 439

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$7.13
25
$6.54
100
$6.03
250
$5.70
500
$5.44
1,000
$5.19
2,500
$4.85
5,000 +
$4.78
Log in for special pricing Click for Quote Price Match Request
