M24308/2-3Z by itt cannon
Image is representational - see manufacturer specifications
ITT CANNON Authorized Distributor

M24308/2-3Z

Conn D-Subminiature SKT 25 POS Crimp ST Panel Mount 25 Terminal 1 Port ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

M24308/2-3Z is a subminiature rectangular connector plug featuring solder-type contacts and a rugged aluminum shell with peripheral seal, designed to meet MIL-C-24308 requirements for aircraft, missile, and ground support equipment applications. The connector incorporates a cadmium-plated aluminum shell with yellow chromate supplementary coating and non-removable factory-installed solder contacts composed of copper alloy with gold plating over nickel. All assemblies are provided with nylon potting cups and dust caps to ensure superior vibration and moisture resistance in demanding environmental conditions. This connector is ideal for applications requiring reliable electrical connections in high-reliability aerospace and defense systems where environmental protection and mechanical durability are critical.

Search Keywords: M2430823Z

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
M24308/2-3Z
Alias/AKA:
130776-0005-MS
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694030
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
SKT
Termination Method:
Crimp
Shell Size:
C
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 150 °C

IN STOCK: 27

Ships today, if you order in

On Order: 125   can ship 2/22/27

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$54.51
5
$37.50
10
$32.76
25
$30.42
50
$28.97
100
$28.90
250 +
$25.86
Log in for special pricing

Tools/3D Models

Product Guides
