M24308/4-1Z by itt cannon
Image is representational - see manufacturer specifications
ITT CANNON Authorized Distributor

M24308/4-1Z

The DEMAM9P is a 9-contact, male D-Subminiature connector from the D*MA series, featuring crimp-style termination for reliable connections. ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The DEMAM9P is a high-reliability D-Subminiature connector from the Cannon D*MA series, designed for crimp termination. It features 9 size 20 male contacts made of copper alloy with a gold-over-nickel finish, supporting a wire gauge range of AWG 20-28. The connector is rated for a maximum current of 7.5A, a dielectric withstanding voltage of 1000 VAC, and is durable for up to 500 mating cycles. Its robust construction includes a tin-plated steel shell and a black thermoplastic insulator, allowing it to operate in a wide temperature range from -55°C to +150°C, making it a reliable choice for various demanding applications.

Search Keywords: M2430841Z

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
M24308/4-1Z
Alias/AKA:
130776-0007-MS
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694030
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
Pin
Termination Method:
Crimp
Shell Size:
E
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
N/A

IN STOCK: 156

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
5
$15.16
25
$12.91
50
$12.16
100
$11.60
250
$10.87
500
$9.87
1,000 +
$9.85
Log in for special pricing

Tools/3D Models

Product Guides
