M83513/01-AN by itt cannon

M83513/01-AN

ITT CANNON

D-Sub Connector - Plug - Male Pins - 9 Positions - 0.050 Pitch x 0.043 Row to Row - 3A - Signal Contact Type - Solder Cup - Free Hanging (In-Line). ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ITT CANNON M83513/01-AN is a high-quality microminiature connector designed for efficient and reliable electrical connections. This connector features a compact and sturdy design, making it perfect for applications requiring a small footprint. With 9 contacts and a 0.05 inch pitch, it allows for precise and secure connections. The male plug configuration and solder terminals ensure a secure and durable connection. The connector is equipped with a hole diameter of 0.096 inches, further enhancing its versatility and compatibility. Whether for aerospace, defense, or industrial applications, the ITT CANNON M83513/01-AN is an excellent choice for your connectivity needs.

Search Keywords: M8351301AN

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
M83513/01-AN
RoHS:
Yes
HTS:
8536694030
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
Pin
Termination Method:
Solder Pot
Shell Size:
N/A
Number of Contacts:
9
Contact Plating:
Gold
Operating Temperature:
N/A

IN STOCK: 2

Can Ship immediately

On Order: 100   can ship 12/15/25

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
1
$47.050
5
$44.960
10
$37.842
25
$35.298
50
$32.919
100
$30.488
250 +
$30.334
