M83513/01-DC by itt cannon
Image is representational - see manufacturer specifications
ITT CANNON Authorized Distributor

M83513/01-DC

Conn D-Subminiature PIN 25 POS 1.27mm Solder Pot ST Panel Mount 25 Terminal 1 Port ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

M83513/01-DC is a microminiature rectangular connector from the MDM (Micro-D Metal Shell) series, designed for high-reliability applications requiring extremely small, lightweight connectors with high-density contact configurations. It features aluminum shells providing EMI/RFI shielding and greater strength, along with a silicone elastomer compression interfacial seal for moisture and humidity protection. The connector offers a dielectric withstanding voltage of 600 VAC at sea level and 150 VAC at 70,000' altitude, insulation resistance of 5,000 megohms minimum, and operates over a thermal shock range of -55°C to +125°C. It withstands physical shock of 50 G's and vibration of 20 G's (10-2,000 Hz), with durability rated for 500 mating cycles. This connector is ideal for aerospace, military, and industrial applications where rugged, moisture-sealed, high-performance microminiature connectors are required.

Search Keywords: M8351301DC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
M83513/01-DC
Alias/AKA:
154176-0000-MS
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694030
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
Pin
Termination Method:
Solder Pot
Shell Size:
N/A
Number of Contacts:
25
Contact Plating:
Gold
Operating Temperature:
N/A

IN STOCK: 18

Can Ship immediately

On Order: 50   can ship 12/23/26

Factory Lead-Time 22 Weeks

Price (USD)

Qty
Unit Price
1
$100.65
5
$99.49
10
$83.75
20
$81.12
50
$74.77
100 +
$71.19
Log in for special pricing

Tools/3D Models

Product Guides
