MDM-21SH041B by itt cannon

MDM-21SH041B

ITT CANNON

D Microminiature Connector ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MDM-21SH041B is a 21-contact Micro "D" metal shell socket connector designed for reliable interconnection in compact electronic assemblies. It features a gold-plated copper alloy contact material with crimp termination, maximum contact resistance of 8 milliohms, and an aluminum shell with yellow chromate/cadmium over nickel finish. The connector is rated for 3 A maximum current per contact and provides 600 VAC dielectric withstanding voltage at sea level (150 VAC at 70,000 ft altitude), with insulation resistance exceeding 5000 megohms. It operates across a thermal shock range of -55°C to +125°C, withstands 50 g physical shock (3 axes, 6 millisecond sawtooth pulse) and 20 g vibration (10–2000 Hz for 12 hours), and is rated for 500 mating/unmating cycles at up to 500 cycles per hour. This connector is commonly used in aerospace, military, and industrial applications requiring compact, high-reliability interconnections in harsh environments.

Search Keywords: MDM21SH041B

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
MDM-21SH041B
Alias/AKA:
096515-0047
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544429090
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Gender:
Socket

IN STOCK: 11

Can Ship immediately

MOQ for out of Stock Qty: 3

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
1
$466.65
3
$465.48
5
$343.74
8
$255.12
10 +
$250.01
