MDM-25PH003L by itt cannon

MDM-25PH003L

ITT CANNON

Conn Micro-D PIN 25 POS 0.64mm Crimp ST Cable Mount 25 Terminal 1 Port ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ITT Cannon MDM-25PH003L is a high-performance micro mini D-sub connector designed to deliver reliable connections in demanding environments. Featuring 25 pins, this connector is ideal for applications requiring compact solutions without compromising on durability or electrical performance. Its robust construction ensures long-lasting resilience against mechanical wear, while the gold-plated contacts enhance conductivity and prevent corrosion. Engineered for versatility, the MDM-25PH003L is perfect for use in aerospace, military, and industrial applications where high-density, miniature connectors are essential. Easy to integrate, this connector supports efficient assembly and is compatible with a wide range of cable types, providing a dependable solution for all your connectivity needs. Trust in ITT Cannon's legacy of quality and innovation with the MDM-25PH003L connector.

Search Keywords: MDM25PH003L

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
MDM-25PH003L
RoHS:
Yes
HTS:
8544429090
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Vibration:
20Gs, 10-2000 Hz. 12 hours
Contact Material:
gold plated copper alloy
Hardware:
Jackscrew (low profile)
Shell Material:
Aluminum
Disclaimer:
Our facility is not currently certified by the DLA and this product is not covered by the QPL/QML.
Arrangement:
25 Contact
Coupling:
Jackscrew Coupling
Insulator Material:
contact size 9 to100 = liquid crystalline polymer, contact arrangements 7C2 or 24C4 = Diallyl phthalate
Termination Type:
18" Min, M16874/4 #26AWG, Colored Code
Insulator Resistance:
5000 megohms min.
Moisture Resistance:
Insulator resistance > 100 megohms
Shell Finish:
Yellow Chromate/Cadmium over Nickel
Contact Resistance:
8 milliohms max.
Dielectric Withstanding Voltage:
600 VAC at sea level 150 VAC at 70,00 altitude
Saltspray:
48 hours
Thermal Shock:
-55°/+125 °
Current Rating:
3 A max.
Durability Rating:
500 cycles of mating and unmating, 500 CPH max.
Gender:
Pin
Series:
Micro "D" Metal Shell
Contact Type:
Crimp
Physical Shock:
50 Gs, 3 axes, 6 milisecond duration sawtooth pulse

IN STOCK: 48

Ships today, if you order in

On Order: 2   can ship 12/22/25

MOQ for out of Stock Qty: 3

Factory Lead-Time 18 Weeks

Price (CAD)

Qty
Unit Price
1
$340.607
3
$335.600
5
$333.916
8
$332.246
10 +
$293.183
