MDM-7C2PH041B

A Micro-D metal shell connector featuring a mixed layout of 5 signal and 2 coaxial pin contacts designed for crimp termination. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The MDM-7C2PH041B is a Micro-D metal shell connector with 5 signal and 2 coaxial pin contacts. It is constructed with an aluminum shell finished with yellow chromate/cadmium over nickel and features gold-plated copper alloy crimp contacts. The connector is rated for a maximum current of 3A, a dielectric withstanding voltage of 600 VAC at sea level, and an insulator resistance of 5000 megohms minimum. Designed for robust performance, it operates across a temperature range of -55°C to +125°C and is rated for 500 mating cycles. Its durability against shock, vibration, and moisture makes it suitable for demanding applications requiring reliable mixed-signal connections.

Product Highlights:

Potential Applications:

Search Keywords: MDM7C2PH041B

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

ITT CANNON

Part No:

MDM-7C2PH041B

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544429090

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
