MDM-9PCBRP by itt cannon
Image is representational - see mfr. specs

MDM-9PCBRP

ITT CANNON

D Microminiature Connector - 9 Contact - Male - 0.05 inch Pitch - Solder Terminal - #2-56 - Plug ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ITT CANNON MDM-9PCBRP is a D microminiature connector designed for rugged applications requiring reliable and high-speed connectivity. With 9 contacts, this connector is ideal for transmitting signals and power in tight spaces. The male plug features a 0.05 inch pitch and solder terminals for a secure and durable connection. Additionally, the #2-56 threaded coupling mechanism ensures easy mating and unmating. Trust ITT CANNON for superior performance and durability in your microminiature connectivity needs with the MDM-9PCBRP.

Search Keywords: MDM9PCBRP

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
MDM-9PCBRP
Alias/AKA:
096510-0229
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Micro D-Subminiature3530
Body Orientation:
Right Angle3506
Mounting:
Through Hole3516
Gender:
Pin
Termination Method:
Solder3529
Shell Size:
E3527
Number of Contacts:
9
Contact Plating:
Gold3509
Operating Temperature:
-55 to 125 °C

IN STOCK: 23

Can Ship immediately

On Order: 50   can ship 7/9/26

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
1
$124.22
5
$119.97
10
$104.04
20
$100.79
50
$92.89
100 +
$90.55
Log in for special pricing Click for Quote Price Match Request
