MS3102E18-10P by itt cannon
Image is representational - see mfr. specs

MS3102E18-10P

ITT CANNON

Conn Circular PIN 4 POS Solder ST Box Mount 4 Terminal 1 Port ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

MS3102E18-10P is a circular military-standard connector conforming to MIL-C-5015 specifications, designed as a box mounting receptacle with threaded coupling. It features 4 contacts of size 12 with hard silver plating, solder cup contact type, and a contact rating of 41 A at +20°C. The connector is constructed from aluminum alloy shell with olive drab chromate coating over cadmium plating, neoprene insulator and grommet material, and copper alloy contacts, providing robust performance in demanding environments. With an operating temperature range of -55°C to +125°C, test voltage of 1600 Vrms, and 500-hour salt spray resistance, this connector is ideal for military, aerospace, and industrial applications requiring reliable high-current connections in harsh conditions.

Search Keywords: MS3102E1810P

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
MS3102E18-10P
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694020
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Ambient Temperature:
Standard insulator material -55°/+125°C (-67/257°F)
Air And Creepage Paths (Min):
1,1 mm

IN STOCK: 57

Ships today, if you order in

On Order: 60   can ship 5/19/26

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$40.33
5
$37.45
10
$35.54
25
$29.96
50
$27.63
100
$24.65
250 +
$23.24
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
