XLR432 by itt cannon
Image is representational - see mfr. specs

XLR432

ITT CANNON

Conn XLR Connector M 4 POS Solder Cup ST Panel Mount 4 Terminal 1 Port ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The XLR432 is a rugged audio connector designed for professional microphone, test instrument, and audio equipment applications. It features a resilient socket insulator that maximizes performance in humid conditions while minimizing vibration and electrical noise, combined with highly reliable machined copper-alloy silver contacts and a quick-disconnect latch lock mechanism. The connector is rated for 5–15 A depending on contact arrangement, with a service voltage of 133 VAC and dielectric withstanding voltage of 1400 VAC, along with insulation resistance of 5000 MO minimum at 500 VDC. The aluminum-alloy shell with satin nickel finish and low reflectivity design provides durability for extreme field use, and the connector is interchangeable and intermateable with XLB2, XLA, XLG, XLB-PC, and XLM series connectors. Common applications include microphones, speakers, TV cameras, amplifiers, mixers, and medical instruments.

Search Keywords: XLR432

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
XLR432
Alias/AKA:
127007-0101
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Type:
XLR Connector
Gender:
M
Body Orientation:
Straight
Mounting:
Panel Mount
Housing Material:
Chloroprene
Number of Contacts:
4
Contact Plating:
Silver
Termination Method:
Solder Cup
Operating Temperature:
-55 to 125 °C

IN STOCK: 0

On Order: 100   can ship 8/17/26

Minimum Order Quantity: 10

Multiple: 10

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
10
$10.85
30
$9.94
50
$9.59
100
$9.06
250
$8.46
500
$8.05
1,000 +
$7.66
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
