105-0610-001 by johnson / cinch connectivity solutions
Image is representational - see mfr. specs

105-0610-001

Johnson / Cinch Connectivity Solutions

Assembly, Tip Jack For Diameter .080 Plug, Blue ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 105-0610-001 is an insulated deluxe tip jack connector designed for reliable audio and signal transmission in professional and consumer applications. It features a machined brass contact with wrap-around beryllium copper spring, silver finish, and a nylon 6/6 body that is UL approved for self-extinguishing properties. The connector is rated for 10 amps continuous current with a breakdown voltage of 5700 Vrms minimum and maintains a contact resistance of 0.010 ohms maximum, ensuring low-loss signal integrity. The design includes a hex socket head for ease of mounting, closed entry design that blocks probes greater than 0.085 inches, and accommodates standard tip plugs with 0.080 inch diameter. With a maximum panel thickness rating of 0.437 inches and a body thread stripping torque of 0.4 lb-in, this connector is ideal for instrument panels, audio equipment, and test equipment where durability and reliable electrical contact are essential.

Search Keywords: 1050610001

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
105-0610-001
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BAG
Type:
Tip Jack
Gender:
F
Body Orientation:
Straight
Mounting:
Panel Mount
Number of Contacts:
1
Wire Size:
N/A
Housing Color:
Blue
Maximum Current Rating:
10 A
Operating Temperature:
N/A
Dimension:
23.82 x 9.53 mm

IN STOCK: 597

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
100
$2.00
300
$1.91
500
$1.85
1,000
$1.72
2,500
$1.68
5,000
$1.58
7,500
$1.57
10,000 +
$1.51
Suppliers Standard Package
