142-0701-551 by johnson / cinch connectivity solutions

142-0701-551

Johnson / Cinch Connectivity Solutions

SMA Jack, Right Angle PCB Mount Bulkhead ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Johnson / Cinch Connectivity Solutions part 142-0701-551 is a high-quality connector designed for SMA applications. It offers a wide frequency range of 0Hz to 18GHz, making it suitable for various high-frequency applications. The connector is designed with a 50Ohm impedance, ensuring accurate signal transmission and minimal loss. With a solder-right angle configuration and a through-hole mounting style, this connector is easy to install and provides a secure and reliable connection. The gold-plated finish further enhances its durability and ensures excellent electrical conductivity. Whether for telecommunications, test and measurement, or other RF applications, the Johnson / Cinch Connectivity Solutions part 142-0701-551 is a reliable choice.

Search Keywords: 1420701551

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
142-0701-551
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Bag
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 18 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
19.69 mm

IN STOCK: 3,603

Ships today, if you order in

Minimum Order: 25

Multiple: 25

Factory Lead-Time 8 Weeks

Price (CAD)

Qty
Unit Price
25
$10.857
50
$9.769
100
$9.356
250
$8.943
500
$8.896
1,000
$8.850
2,500 +
$8.806
Suppliers Standard Package
Log in for special pricing
Click for Quote
