142-0701-841 by johnson / cinch connectivity solutions
Image is representational - see mfr. specs

142-0701-841

Johnson / Cinch Connectivity Solutions

SMA Jack Assembly, End Launch ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

142-0701-841 is an SMA jack assembly end-launch connector designed for high-frequency RF applications up to 18 GHz with 50-ohm impedance. The connector features a brass body with gold plating over nickel and copper, combined with beryllium copper gold-plated contacts and a Teflon insulator, providing excellent electrical performance and corrosion resistance. Electrical specifications include a working voltage of 335 VRMS maximum at sea level, dielectric withstanding voltage of 1000 VRMS minimum, insulation resistance of 5000 MO, and contact resistance of 3 milliohms maximum initially. Mechanically, the connector supports a mating torque of 7–10 inch pounds, contact retention of 6 lbs minimum axial force, and 500 cycles minimum durability. Operating temperature range spans -65°C to 165°C, meeting military standards for thermal shock, corrosion, shock, vibration, and moisture resistance. This connector is ideal for aerospace, defense, telecommunications, and precision RF measurement applications requiring reliable high-frequency signal transmission.

Search Keywords: 1420701841

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
142-0701-841
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
BAG
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 18 Hz to GHz
Gender:
RCP
Mounting:
Edge Mount
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
9.52 x 14.27 x 7.92 mm

IN STOCK: 1,186

Ships today, if you order in

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
25
$5.05
50
$4.80
100
$4.52
250
$4.20
500
$4.03
1,000
$4.02
2,500
$4.01
5,000 +
$4.00
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
