142-0701-881 by johnson / cinch connectivity solutions
Image is representational - see manufacturer specifications
Johnson / Cinch Connectivity Solutions Authorized Distributor

142-0701-881

The 142-0701-881 is a 50 Ohm SMA end launch jack assembly designed for RF applications up to 18 GHz. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 142-0701-881 is a 50 Ohm SMA end launch jack assembly. It is engineered to operate over a frequency range from DC to 18 GHz. Key electrical characteristics include a working voltage of 335 VRMS maximum, a dielectric withstanding voltage of 1000 VRMS minimum, and an insulation resistance of 5000 megohms minimum. Mechanically, it features a mating torque of 7-10 inch-pounds and is rated for a durability of at least 500 cycles. This connector is built to withstand harsh conditions, meeting MIL-STD-202 for thermal shock, corrosion, shock, and vibration, with an operating temperature range of -65°C to 165°C.

Search Keywords: 1420701881

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
142-0701-881
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
BAG
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 18 Hz to GHz
Gender:
RCP
Mounting:
Edge Mount
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
9.52 x 14.27 x 7.92 mm

IN STOCK: 475

Ships today, if you order in

On Order: 1,000   can ship 9/30/26

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
25
$8.90
50
$8.34
100
$7.81
250
$7.79
500
$7.77
1,000
$7.75
2,500 +
$7.73
Supplier's Standard Package
