142-1901-821 by johnson / cinch connectivity solutions
Image is representational - see mfr. specs

142-1901-821

Johnson / Cinch Connectivity Solutions

SMA, In Series, Jack To Quick Connect Plug Adapter, 18 GHz ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 142-1901-821 is an SMA Jack to Quick Connect Plug Adapter designed to convert standard SMA plug test cables into quick-connect cables for efficient testing. It features a push-and-twist connection mechanism that achieves full MIL-PRF-39012 electrical compatibility, with rapid disconnect accomplished via a twist-and-pull motion. The adapter supports frequencies up to 18 GHz and is engineered to withstand up to 1000 mating cycles, ensuring robust mechanical performance. The knurled thumbnut requires only one half to one full turn to create a solid electromechanical connection. This adapter is ideal for test and measurement lab equipment and instrumentation test fixture hardware, where rapid cable connections and disconnections are essential for improving testing efficiency.

Search Keywords: 1421901821

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
142-1901-821
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
SMA Adapter
Impedance:
50 Ohm
Operating Frequency:
0 to 18 Hz to GHz
Gender:
PL/F
Mounting:
N/A
Body Orientation:
Straight
Terminate To:
N/A
Termination Method:
N/A
Operating Temperature:
N/A
Dimension:
27.74 x 12.83 mm

IN STOCK: 47

Can Ship immediately

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$54.77
5
$54.14
10
$46.02
25
$42.71
50
$40.67
100
$38.74
250 +
$36.23
