142-4701-501

SMA Jack Right Angle, PCB Mount Bulkhead, Reverse Polarity ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 142-4701-501 is a reverse polarity SMA jack assembly designed for PC mount bulkhead applications. It features a brass body with gold plating (0.00001 inch minimum over nickel and copper), gold-plated brass contacts (0.00003 inch minimum over nickel and copper), and a TFE/LON insulator body for reliable RF performance. The assembly includes a bronze gold-plated insulator and brass gold-plated nut and base components, with a 1/4-36 UNS-2A thread specification and 0.312 inch hex dimension. Operating over a temperature range of -65°C to +165°C with a minimum durability rating of 500 cycles, this connector meets or exceeds MIL-PRF-39012 environmental standards including thermal shock, corrosion, shock, vibration, and moisture resistance testing per MIL-STD-202. This connector is ideal for high-reliability RF and microwave applications requiring reverse polarity protection and robust environmental performance.

Search Keywords: 1424701501

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
142-4701-501
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
BAG
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 18 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
19.69 mm

IN STOCK: 1

Ships today, if you order in

Buy all 1 in-stock or the regular minimum order quantity of 5

On Order: 500   can ship 10/19/26

Stock lot only: 1

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$20.269
5
$18.427
25
$15.687
50
$14.791
100
$14.090
250
$13.205
500
$12.576
1,000 +
$12.545
