1201M2S3AQE2 by littelfuse/c-k
Image is representational - see mfr. specs

1201M2S3AQE2

Littelfuse/C&K

Miniature Slide Switch ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1201M2S3AQE2 is a miniature DPDT slide switch from the C&K 1000 Series, designed for power switching applications. It features silver contact material with a contact rating of 6 AMPS @ 120 V AC or 28 V DC, and 3 AMPS @ 250 V AC, along with quick connect termination and epoxy terminal seal for bottom-wash cleaning compatibility. The switch offers contact resistance below 10 mO typical, insulation resistance of 10? O minimum, and dielectric strength of 1,000 Vrms minimum at sea level. With an operating temperature range of -30°C to 65°C and electrical life of 40,000 make-and-break cycles at full load, this RoHS compliant switch is suitable for test and measurement equipment, telecommunications, and computer peripherals.

Search Keywords: 1201M2S3AQE2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
1201M2S3AQE2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
80
Package Type:
TRAY
Mounting:
PCB Through Hole
Body Orientation:
Right Angle
Actuator Style:
Side Slide
Pole Throw Configuration:
DPDT
Switch Configuration:
On None On
Contact Rating @ Voltage:
6@120VAC 28VDC A
Contact Plating:
Silver
Operating Temperature:
-30 to 65 °C
Termination Style:
PC Pins
Dimension:
13.57 x 22.49 x 11.43 mm

IN STOCK: 370

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$12.24
25
$11.05
80
$9.42
160
$9.21
320
$8.97
560
$8.64
1,040 +
$8.30
Suppliers Standard Package
