312100N03 by littelfuse/c-k
Image is representational - see mfr. specs

312100N03

Littelfuse/C&K

Thumbwheel Switch ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 312100N03 is a PHA Series short-stroke pushbutton switch designed for low-cost, reliable switching applications. It features momentary or push-push latching action with 2 or 4 pole changeover contact configurations, sealed contacts for environmental protection, and optional button styles including indexed, rectangular, round, and square designs in multiple colors. The switch operates at a maximum switching power of 3 W DC and 30 V DC with a maximum switching current of 100 mA DC, providing a contact resistance of 20 mO initial and an insulation resistance of 100 MO. With a total travel of 2.5 mm and an operating force of 170–230 grams, the switch delivers 10,000 cycles of operating life at rated load and operates reliably across a temperature range of -10°C to 60°C. This switch is ideal for computers, peripherals, instrumentation, and measurement equipment where non-power on-off switching is required.

Search Keywords: 312100N03

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
312100N03
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
150
Package Type:
Tray
Actuator Style:
Thumbwheel
Circuit Code:
BCD
Number of Positions:
10
Mounting:
Panel, Snap In Front
Contact Rating @ Voltage:
0.1 A
Maximum AC Voltage Rating:
120 V
Maximum DC Voltage Rating:
28 V
Maximum Contact Resistance:
100 mOhm
Operating Temperature:
-40 to 65 °C
Termination Style:
PC Pins
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 7

Ships today, if you order in

Minimum Order Quantity: 2

Price (USD)

Qty
Unit Price
1
$235.698
10
$214.271
25
$211.068
38
$207.895
75
$111.189
113
$76.127
150 +
$74.603
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
