7201SHZQE by littelfuse/c-k
Image is representational - see mfr. specs

7201SHZQE

Littelfuse/C&K

Miniature Toggle Switch - DP (On-None-On) - 5A@120VAC/2A@250VAC - .420" Actuator - Solder Lug - 1/4-40 Bushing - Epoxy Seal ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 7201SHZQE is a miniature DPDT toggle switch from the C&K 7000 Series designed for reliable switching applications. It features a double-pole double-throw configuration with solder lug (Z) termination and epoxy seal protection, operating over a temperature range of -30°C to 85°C. The switch has a contact resistance below 10 mO typical at 2-4 V DC with 100 mA, and an insulation resistance of 10? O minimum with 1000 Vrms dielectric strength. It is rated for 40,000 electrical cycles at full load and supports contact materials including silver and gold plated options that are RoHS compliant. The 7201SHZQE is commonly used in industrial control panels, instrumentation, and consumer electronics where compact, reliable switching with solder termination is required.

Search Keywords: 7201SHZQE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
7201SHZQE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BULK
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
ON None ON14118
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Round Lever14088
Mounting:
Panel Mount with Threads14108
Thread Size:
1/4-4014120
Body Orientation:
Straight14091
Terminal Type:
Solder Lug14119
Dimension:
12.7mm x 11.43mm x 32.5514112mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 90

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 25

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$16.29
10
$13.66
25
$13.13
50
$12.71
75
$12.68
100 +
$11.29
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
