7203TZQE by littelfuse/c-k
Image is representational - see mfr. specs

7203TZQE

Littelfuse/C&K

Miniature Toggle Switch - DP (On-Off-On) - 5A@120VAC/2A@250VAC - .687" Actuator - Solder Lug - No Thread Bushing - Epoxy Seal ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 7203TZQE is a dual-pole, on-off-on miniature toggle switch from the C&K 7000 Series, featuring a DPDT (double-pole, double-throw) switching configuration with on-off-on functionality. The switch incorporates a T-style actuator measuring 0.687 inches high with a 15/32 bushing, an epoxy terminal seal, and nickel-plated brass hardware for durability. Key electrical specifications include a contact rating of 5 amps at 120 V AC or 28 V DC (2 amps at 250 V AC for Q contact material), contact resistance below 10 mO typical, insulation resistance of 10? O minimum, and dielectric strength of 1000 Vrms minimum at sea level. The switch operates reliably over a temperature range of -30°C to +85°C with an electrical life of 40,000 make-and-break cycles at full load. This switch is ideal for control applications requiring robust, compact switching in industrial equipment, instrumentation, and consumer electronics where reliable on-off-on operation is essential.

Search Keywords: 7203TZQE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
7203TZQE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BULK
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
ON OFF ON14118
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Round Lever14088
Mounting:
Panel Mount with Threads14108
Thread Size:
15/32-3214120
Body Orientation:
Straight14091
Terminal Type:
Solder Lug14119
Dimension:
12.7mm x 11.43mm x 42.1714112mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 48

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$18.898
5
$17.180
25
$15.594
50
$14.750
100
$13.781
300
$13.328
500
$13.153
1,000 +
$13.091
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
