8225SD9AV2BE by littelfuse/c-k
Image is representational - see mfr. specs

8225SD9AV2BE

Littelfuse/C&K

Snap-acting Momentary Pushbutton Switches ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 8225SD9AV2BE is a snap-acting momentary pushbutton switch from the 8020 Series featuring DPDT (double-pole double-throw) contact configuration with vertical right-angle PC thru-hole termination at 0.150" pitch. This switch delivers positive tactile feedback and is designed for reliable operation with contact ratings of 1 AMP at 120 V AC or 28 V DC, with an electrical life of 60,000 make-and-break cycles at full load. The switch incorporates an epoxy terminal seal compatible with bottom wash cleaning and features low contact resistance below 50 mO typical at 2-4 V DC with 100 mA. Typical applications include instrumentation, computer peripherals, and telecommunications equipment where dependable switching performance and compact form factor are essential.

Search Keywords: 8225SD9AV2BE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
8225SD9AV2BE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
80
Package Type:
TRAY
Mounting:
Through Hole
Pole Throw Configuration:
DPDT
Bushing Type:
Unthreaded
Switch Configuration:
ON Mom
Contact Rating @ Voltage:
0.4A@20VAC 20 VDC
Actuator Style:
Round Plunger
Illumination:
N/R
Terminal Type:
PC Pins
Body Orientation:
Vertical Right Angle
Dimension:
11.43 x 33.6 x 12.7 mm

IN STOCK: 445

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
5
$10.19
25
$9.68
80
$9.32
160
$9.07
320
$9.05
560
$8.96
1,040 +
$8.90
