8261SHZQE2 by littelfuse/c-k
Image is representational - see mfr. specs

8261SHZQE2

Littelfuse/C&K

Alternate Action and Momentary Pushbutton Switches ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 8261SHZQE2 is a DPDT (double-pole double-throw) pushbutton switch from the 8060 Series designed for alternate action and momentary switching applications. It features a coin silver contact material with silver plating, copper alloy center contacts and terminals also silver plated, and an epoxy terminal seal compatible with bottom-wash PCB cleaning methods. The switch delivers a contact rating of 6 amps at 120 V AC or 28 V DC (3 amps at 250 V AC), with contact resistance below 20 mO typical at 2–4 V DC and 100 mA, and an electrical life of 50,000 make-and-break cycles at full load. Operating temperature range is -30°C to 65°C, with dielectric strength of 1,000 Vrms minimum at sea level and insulation resistance of 10? O minimum. This switch is ideal for instrumentation, computers and peripherals, and telecommunications equipment where reliable switching performance and long operational life are required.

Search Keywords: 8261SHZQE2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
8261SHZQE2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509035
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag
Mounting:
Panel Mount
Pole Throw Configuration:
DPDT
Bushing Type:
Threaded
Switch Configuration:
On On
Contact Rating @ Voltage:
6A@120VAC 28 VDC
Actuator Style:
Round Plunger
Illumination:
Red,LED
Terminal Type:
Solder
Body Orientation:
Straight
Dimension:
12.7 x 11.43 x 33.5 mm

IN STOCK: 96

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 500

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$19.10
100
$13.71
250
$13.64
500
$13.57
1,000
$13.50
1,500
$13.43
2,000 +
$13.37
