8531J81ZQE22 by littelfuse/c-k
Image is representational - see mfr. specs

8531J81ZQE22

Littelfuse/C&K

Subminiature Pushbutton Switches ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

8531J81ZQE22 is a subminiature pushbutton switch from C&K Components' 8500 Series, designed for detection, telecommunications, and computer peripheral applications. This single-pole single-throw (SPST) normally open momentary switch features a total travel of 0.095" (2.41 mm) typical with 0.042" (1.07 mm) overtravel, and an actuation force of 7.7 oz (220g) typical. The switch is equipped with a J81 snap-in frame actuator for panel mounting (panel thickness 0.047" to 0.125"), solder lug (Z) terminations, and Q contact material rated at 1 AMP @ 120 V AC or 28 V DC. It offers reliable contact design with contact resistance below 30 mO typical, insulation resistance of 10?O minimum, and an electrical life of 250,000 actuations at full load. The switch operates over a temperature range of -30°C to 65°C and is RoHS compliant.

Search Keywords: 8531J81ZQE22

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
8531J81ZQE22
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
80
Package Type:
TRAY
Mounting:
Panel Mount
Pole Throw Configuration:
SPST
Bushing Type:
Threaded
Switch Configuration:
OFF Mom
Contact Rating @ Voltage:
1A@120VAC 28 VDC
Actuator Style:
Square Button
Illumination:
N/R
Terminal Type:
Solder
Body Orientation:
Straight
Dimension:
9.53 x 9.53 x 27.62 mm

IN STOCK: 160

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 40

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$11.02
10
$9.53
25
$8.97
40
$8.87
80
$7.83
120
$7.81
160 +
$7.32
