8532SCQE3 by littelfuse / c-k
Image is representational - see manufacturer specifications
Littelfuse / C&K Authorized Distributor

8532SCQE3

Subminiature Pushbutton Switches ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 8532SCQE3 is a subminiature SPST (Single Pole Single Throw) momentary pushbutton switch from the 8500 Series, designed for applications requiring compact, reliable switching. It features a 1 AMP contact rating at 120 V AC or 28 V DC, with a typical total travel of 0.050 inches and an actuation force of 6 ounces. The switch incorporates silver contact material (Q option) with a contact resistance below 30 mO typical, an insulation resistance of 10? O minimum, and dielectric strength of 1,000 Vrms minimum. The device operates reliably over a temperature range of -30°C to 65°C and features an epoxy terminal seal with brass nickel-plated hardware. This switch is ideal for detection, telecommunications, networking equipment, and computer peripherals where space constraints and reliable momentary switching are essential.

Search Keywords: 8532SCQE3

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse / C&K
Part No:
8532SCQE3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509031
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
80
Package Type:
TRAY
Mounting:
Panel Mount/Through Hole
Pole Throw Configuration:
SPST
Bushing Type:
Threaded
Switch Configuration:
OFF Mom
Contact Rating @ Voltage:
1A@120VAC 28 VDC
Actuator Style:
Round Plunger
Illumination:
N/R
Terminal Type:
PC Pins
Body Orientation:
Straight
Dimension:
9.53 x 9.53 x 21.74 mm

IN STOCK: 30

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks
