BD03 by littelfuse/c-k
Image is representational - see mfr. specs

BD03

Littelfuse/C&K

Standard Profile DIP ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

BD03 is a 3-position SPST standard profile DIP switch designed for address switching and logic control applications. It features an extended actuator for easy actuation, open bottom construction for solder washing, and is RoHS compliant. The switch offers a contact rating of 100 mA max at 50 V DC (carry) and 100 mA max at 5 V DC (switch), with contact resistance below 50 milliohms typical. Operating temperature ranges from -40°C to 85°C, and the switch provides 10,000 make-and-break cycles of mechanical and electrical life. Common applications include address switches for industrial controls, logic switching for computers and peripherals, and function controlling for various equipment.

Search Keywords: BD03

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
BD03
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
54
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Extended Slide
Actuator Length:
0.9 mm
Number of Positions:
3
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.1@5VDC A
Contact Plating:
N/A
Terminal Pitch:
2.54 mm

IN STOCK: 41,112

Ships today, if you order in

Minimum Order Quantity: 54

Multiple: 54

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
1
$1.677
54
$1.524
270
$1.391
540
$1.329
1,026
$1.277
2,538
$1.195
5,022
$1.143
7,506
$1.112
10,044 +
$1.082
