BD08 by littelfuse/c-k

BD08

Littelfuse/C&K

Standard Profile DIP switch-100 mA max. @ 50 V DC.-Thru-hole-Unsealed-2N-8 positions ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The BD08 with dimensions 22.35mm x 9.65mm x 7.54mm has Thru-hole mounting with SPST Pole throw configuration ,SPST switching configuration and Slide Standard actuator. The BD08 has operating force of 2 N and contact rating of 100mA@50V. This unsealed switch has thru-hole termination style with Straight body orientation.With an extended actuator for easy actuation and an open bottom construction that allows for solder washing without the need for a tape seal, BD series standard profile DIP switches from C&K are used by designers for function controlling, logic switching in computers and peripherals and industrial control address switches and automotive applications.

Search Keywords: BD08

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
BD08
RoHS:
Yes
HTS:
8536509050
COO:
VN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
23
Package Type:
Tube
Body Orientation:
Straight
Actuator Style:
Extended Slide
Actuator Length:
0.9 mm
Number of Positions:
8
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.1@5VDC A
Contact Plating:
N/A
Terminal Pitch:
2.54 mm

IN STOCK: 13,452

Ships today, if you order in

Minimum Order: 23

Multiple: 23

Factory Lead-Time 6 Weeks

Price (CAD)

Qty
Unit Price
23
$2.374
115
$2.129
253
$2.068
506
$2.037
1,012
$1.991
2,507
$1.959
5,014 +
$1.945
