D6F90F1LFS by littelfuse/c-k
Image is representational - see mfr. specs

D6F90F1LFS

Littelfuse/C&K

Switch Key N.O. SPST 0.1A 32VDC 3VA 1.3N PC Pins Thru-Hole Box ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

D6F90F1LFS is an SPST momentary key switch from the D6 series featuring a flat actuator style with black color and standard 1.3N operating force. It provides a normally open contact arrangement with positive tactile feedback, switching travel of 0.2mm to 1.0mm, and operating force range of 0.8N to 1.8N. The switch offers electrical ratings of 32V DC maximum switching voltage, 100mA DC maximum switching current, and 3VA maximum switching power with contact resistance of =100mO. It operates over a temperature range of -20°C to 85°C and is compatible with wave soldering and lead-free soldering processes. This RoHS compliant switch is suitable for applications in video equipment, electronic games, and appliances where reliable momentary switching with tactile feedback is required.

Search Keywords: D6F90F1LFS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
D6F90F1LFS
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Package Type:
TRAY
Pole Throw Configuration:
SPST13608
Body Orientation:
Straight13581
Maximum Current Rating:
0.1 A
Mounting:
Through Hole13603
Switch Configuration:
N.O.13613
Terminal Type:
PC Pins13615
Total Travel:
N/A
Dimension:
11.4mm x 12mm x 7.313610mm
Actuator Style:
Flush Button13580
Operating Force:
1.3 N
Illumination Type:
N/R
Illumination Color:
N/R

IN STOCK: 75,103

Ships today, if you order in

Minimum Order Quantity: 250

Multiple: 250

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
250
$0.976
500
$0.933
1,000
$0.893
2,500
$0.857
5,000
$0.833
7,500
$0.831
10,000
$0.823
15,000 +
$0.821
