D6R30F1LFS by littelfuse / c-k
Image is representational - see manufacturer specifications
Littelfuse / C&K Authorized Distributor

D6R30F1LFS

Switch Key N.O. SPST 0.1A 32VDC 3VA 1.3N PC Pins Thru-Hole Box ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

D6R30F1LFS is an SPST momentary key switch from the C&K D6 series featuring a round actuator style in yellow color. This switch offers positive tactile feedback with a nominal operating force of 1.3N (range 0.8N to 1.8N) and switching travel of 0.2mm to 1.0mm. It is rated for a maximum switching power of 3 VA, switching voltage of 32 V DC, and switching current of 100 mA DC, with contact resistance of =100 mO. The switch operates over a temperature range of -20°C to 85°C and is compatible with wave soldering and lead-free soldering processes. Typical applications include video equipment, electronic games, and appliances where reliable momentary switching with tactile feedback is required.

Search Keywords: D6R30F1LFS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse / C&K
Part No:
D6R30F1LFS
Alias/AKA:
Y41A00512FPLFS
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509031
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
250
Package Type:
TRAY
Pole Throw Configuration:
SPST
Body Orientation:
Straight
Maximum Current Rating:
0.1 A
Mounting:
Through Hole
Switch Configuration:
N.O.
Terminal Type:
PC Pins
Total Travel:
N/A
Dimension:
11.4mm x 12mm x 14.3 mm
Actuator Style:
Round Button
Operating Force:
1.3 N
Illumination Type:
N/R
Illumination Color:
N/R

IN STOCK: 4,652

Can Ship immediately

Minimum Order Quantity: 250

Multiple: 250

Factory Lead-Time 15 Weeks
