KMR231GLFS by littelfuse/c-k
Image is representational - see mfr. specs

KMR231GLFS

Littelfuse/C&K

Microminiature SMT Top Actuated-Surface Mount-SPST-0.05A@32VDC-3N-Sealed - IP40 ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The KMR231GLFS with dimensions 4.6mm x 2.8mm x 1.9 mm has Surface Mount mounting with SPST Pole throw configuration ,SPST switching configuration and Standard actuator. The KMR231GLFS has operating force of 3N and contact rating of 50mA@32V. This Sealed - IP40 switch has Gull Wing termination style with Top Actuated body orientation. Highly responsive with its excellent tactile feel and is long-lasting to withstand harsh environments. It has ultra-low current capabilities and is ideal for industrial, medical and automotive applications.

Search Keywords: KMR231GLFS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
KMR231GLFS
Alias/AKA:
Y78B23110FP
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536501
COO:
FR
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
7000
Package Type:
REEL
Dimension:
4.6 x 2.8 x 1.9 mm
Mounting:
PCB Surface Mount
Pole Throw Configuration:
SPST
Switch Configuration:
N.O.
Actuator Style:
Button
Operating Force:
3 N
Contact Rating @ Voltage:
1 A
Illumination Type:
N/R
Body Orientation:
Straight
Termination Style:
Gull Wing
Seal:
N/A
Seal Location:
N/A

IN STOCK: 87,534

Ships today, if you order in

Minimum Order Quantity: 1000

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1,000
$0.2457
2,500
$0.2384
7,000
$0.2362
14,000
$0.2350
21,000
$0.2338
28,000
$0.2327
56,000 +
$0.2314
Reel Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
