KSR223GLFG by littelfuse/c-k
Image is representational - see mfr. specs

KSR223GLFG

Littelfuse/C&K

Subminiature Tact Switch for SMT ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The C&K COMPONENTS part KSR223GLFG is a subminiature tact switch designed specifically for surface mount technology (SMT) applications. With its compact size and high-quality construction, this tact switch is ideal for space-constrained electronic devices where reliable and precise tactile feedback is required. The KSR223GLFG is built to withstand rigorous use, ensuring longevity and durability. Whether used in consumer electronics, medical equipment, or industrial applications, this subminiature tact switch is a dependable choice for a wide range of SMT projects.

Product Highlights:

  • Saves PCB space
  • Range of 4 actuation forces
  • G terminations
  • Detect type available
  • Rubber actuator
  • IP 50 sealed

Search Keywords: KSR223GLFG

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
KSR223GLFG
Alias/AKA:
Y35A22310FPLFG
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536501
COO:
FR
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
2500
Package Type:
REEL
Dimension:
7.3 x 3.8 x 2.5 mm
Mounting:
PCB Surface Mount
Pole Throw Configuration:
SPST
Switch Configuration:
N.O.
Actuator Style:
Round Button
Operating Force:
2 N
Contact Rating @ Voltage:
0.2 A
Illumination Type:
N/R
Body Orientation:
Straight
Termination Style:
Gull Wing
Seal:
N/A
Seal Location:
N/A

IN STOCK: 82,160

Ships today, if you order in

Minimum Order Quantity: 500

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
500
$0.570
1,000
$0.560
2,500
$0.552
5,000
$0.549
7,500
$0.546
10,000
$0.544
15,000
$0.541
25,000 +
$0.538
Reel Package
