MB00L1NZQF by littelfuse/c-k
Image is representational - see mfr. specs

MB00L1NZQF

Littelfuse/C&K

Rotary Switch - DP5T - 5 Positions - 1 Deck, 2 Poles/Desk - 10.16mm Flatted (3.17mm Dia) Actuator - 36° Angle of Throw - Solder Lug - Panel Mount. ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MB00L1NZQF from Littelfuse/C&K is panel mount double pole five throw (DP5T) rotary switch with 1 deck, 2 poles/desk and solder lug termination. This 5 positions rotary switch has 10.16mm long flatted (3.17mm dia) actuator and 36° angle of throw. This M series is used most often in test, industrial and medical equipment. Operating temperature range is from -30°C to 85°C.

Search Keywords: MB00L1NZQF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
MB00L1NZQF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
80
Package Type:
TRAY
Number of Positions:
5
Pole Throw Configuration:
DP5T
Actuator Length:
10.16 mm
Dimension:
13.34 x 13.34 x 31.37 mm
Actuator Style/Diameter:
Flatted Shaft/3.17
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
36 °
Contact Rating @ Voltage:
0.25@125VAC 28VDC A

IN STOCK: 130

Can Ship immediately

MOQ for out of Stock Qty: 20

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$39.45
5
$38.86
10
$38.27
20
$37.71
40
$23.21
60
$18.36
80 +
$18.00
Suppliers Standard Package
