SDA01H1BD by littelfuse/c-k
Image is representational - see manufacturer specifications
Littelfuse/C&K Authorized Distributor

SDA01H1BD

Low Profile DIP ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

SDA01H1BD is a single-position low-profile DIP switch from the SDA Series featuring an extended actuator design and thru-hole terminals without top tape seal. The switch is rated for 25 mA @ 24 V DC or 100 mA @ 5 V DC, with a contact resistance of 50 mO maximum and an insulation resistance of 100 MO between terminals. It offers a dielectric withstanding voltage of 300 V DC minimum for 1 minute, mechanical and electrical life of 1,000 cycles at rated loads, and operates reliably across a temperature range of -40°C to +85°C. The switch features a low-profile design that saves space, gold-plated beryllium copper contacts, and is RoHS compliant, making it ideal for address switching in industrial controls, logic switching for computers and peripherals, and general function control applications.

Search Keywords: SDA01H1BD

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
SDA01H1BD
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Raised Slide
Actuator Length:
1 mm
Number of Positions:
1
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.1@5VDC A
Contact Plating:
Gold
Terminal Pitch:
N/R

IN STOCK: 2,150

Can Ship immediately

MOQ for In Stock Qty: 65

MOQ for out of Stock Qty: 65

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
65
$1.58
100
$1.57
250
$1.56
500
$1.18
750
$1.10
1,000 +
$1.08
Supplier's Standard Package
